Medeli DD400 - Connect the Pads to the Drum Module; Mounting the Drum Module; Connecting Pads and Pedals

3
Attach the Drum Module
Connection Procedure
1.
2.
3.
Are you ready? Let's enjoy playing it.
Place the pedal on the floor on your left side.
Place the bass drum pedal on the floor in the center
of rack.
Please connect the clearly marked cables from the
pads to the correct inputs on the drum module.
Connect the Pads to the Drum Module
DD400_G03
1
4
2
3
Cymbal Pad
To Tom1
RideTo
To Crash
Drum Module
To Tom2
To Tom3
To Snare
Drum Pad
1
2
To HI-Hat
PedalHi-Hat
To Hi-Hat control To Kick
Bass Drum Pedal
1.
2. Insert the "L-Metal Rod" to the clamp
3. Insert the drum module to the L-Metal Rod
Tighten the wing screw on the clamp.
Loosen wing nut on the clamp ,
.
.
4.
wich is on the center pipe.
0
5
25
75
95
100
