Document Structure Hardware Installation Guide
Mediatrix C7 Series – Digital Gateway
ix
Document Structure
The Mediatrix C7 Series Hardware Installation Guide contains the following information.
Table 2: Mediatrix C7 Series Hardware Installation Guide Chapter/Appendices
Title Summary
“Chapter 1 -
Overview” on page 1 Provides a brief description of the Mediatrix C7
Series.
“Chapter 2 -
Installation” on page 5 Contains instructions for installing the Mediatrix C7
Series and connecting the cables.
“Chapter 3 -
Powering on the Mediatrix C7
Series” on page 13
Leads you through the basic steps to start the
Mediatrix C7 Series.
“Appendix A - Standards Compliance and Safety
Information” on page 21
Lists the various standards compliance of the
Mediatrix C7 Series.
“Appendix B - Cabling Considerations” on
page 29
Describes the pin-to-pin connections for cables used
with the Mediatrix C7 Series.
“Appendix C - Standard Hardware Information”
on page 87
Lists the technical hardware information of the
Mediatrix C7 Series.
