Getting Started
1-3
On-Board IDE
An IDE controller on the ICH2 chipset provides IDE HDD/CD-ROM with
PIO, Bus Master and Ultra DMA66/100 operation modes.
Can connect up to four IDE devices.
On-Board Peripherals
On-Board Peripherals include:
- 1 floppy port supports 2 FDDs with 360K, 720K, 1.2M, 1.44M and
2.88Mbytes.
- 2 serial ports (COM A + COM B1).
- 1 parallel port supports SPP/EPP/ECP mode.
- 4 USB ports (Rear * 2/Front * 2).
- 1 RJ-45 LAN jack.
- 1 audio/game port.
Audio (optional)
C-Media CMI8738 / PCI-6ch supports 2/4/6 ch speaker.
Network
Realtek RTL8100BL single chip fast 10/100 Mb/s Ethernet controller.
BIOS
The mainboard BIOS provides “Plug & Play” BIOS which detects the pe-
ripheral devices and expansion cards of the board automatically.
The mainboard provides a Desktop Management Interface (DMI) function
which records your mainboard specifications.
Dimension
Micro ATX Form Factor: 24.4cm x 22.4cm.
Mounting
6 mounting holes.
