2-1
Hardware Setup
Chapter 2. Hardware Setup
This chapter tells you how to install the CPU, memory modules, and
expansion cards, as well as how to setup the jumpers on the mainboard.
Also, it provides the instructions on connecting the peripheral devices,
such as the mouse, keyboard, etc.
While doing the installation, be careful in holding the components and
follow the installation procedures.
Hardware Setup
4
6
Table of Contents
Chapter 1. Getting Started
1
Mainboard Specifications
2
Main Memory
2
Mainboard Layout
4
Hardware Setup
5
Quick Components Guide
6
Central Processing Unit (Cpu)
7
Introduction to LGA 775 CPU
7
CPU & Cooler Installation
8
Memory
11
Introduction to DDR SDRAM
11
DDR Population Rules
11
Installing DDR Modules
12
Power Supply
13
ATX 12V Power Connector: JPW1
13
Back Panel
14
Mouse/Keyboard Connector
14
Serial Port Connector: COM Port
15
Ieee1394 Port
15
USB Connectors
16
Audio Port Connectors
16
Parallel Port Connector: LPT1
17
Connectors
18
Floppy Disk Drive Connector: FDD1
18
Hard Disk Connector: IDE1
19
SATA Connectors Controlled by Intel ICH6
20
Front Panel Audio Connector: JAUD1
21
Front USB Connector: JUSB1
22
SCART Output Connector: JSCA1
22
PCI Express Slots
25
PCI (Peripheral Component Interconnect) Slots
25
PCI Interrupt Request Routing
25
