MEDIX Econoneb - Filling the Nebuliser Chamber; Administering the Medication

6.1 Filling the Nebuliser Chamber
For Single Patient Use
1. Connectoneendofthedrivelinetotheoutletlteronyourcompressor.
2. Connect the other end of the driveline to the bottom of the blue nebuliser cup.
3. Remove the nebuliser top from the cup and pour medication into the cup
(max. 10ml.)
4. Screw the top back onto the cup.
5. Connect either the face mask or mouthpiece to the nebuliser top.
All accessories must comply with EN 13544-1
6.2 Administering the Medication
Switch the compressor unit on. Sitting in an upright relaxed position, place mouthpiece into the
mouth (or face mask over the nose and mouth) and start breathing slowly and deeply. Do not try to
breathequickly.Ifyouhaveanyproblemsseekinstructionfromyourdoctororphysiotherapy
departmentatyourhospital.Switchothecompressorwhenthemistinghasstopped.Unplugthe
mains lead.
