HTD8813C/MS-131002 Non-Contact Infrared Body Thermometer
Thermometer Applications
Equipment Symbols
Technical Specifications
Specification Value(s)
Measurement Units Fahrenheit (°F) / Celsius (°C)
Operating Mode Adjusted mode (Body mode)
Direct mode (Surface mode)
Measuring Site Forehead
Reference Body Site Axillary
Rated Output Range Body mode: 95.0 °F – 107.6 °F (35.0 °C – 42.0 °C)
Surface mode: 32.0 °F – 212.0 °F (0.0 °C – 100.0 °C)
Extended Output Range Body mode:
Lower: 93.2 °F – 94.8 °F (34.0 °C – 34.9 °C)
Upper: 107.8 °f – 109.2 °F (42.1 C 42.9 °C)
05
Thermometer
Model Number
Thermometer
Adult Pediatric
Ear Forehead Ear Forehead
59º F
0%
85%
95º F
Warning
Non-Sterile Package
Refer to Operating Instructions
Operating Temperature
Operating Humidity
Manufacturer
Compliance with WEEE Standard
DO NOT THROW AWAY Intended for
multiple uses
Operating atmospheric pressure
Serial number
Recyclable
This device complies with Part 15 of
FCC (Federal Communications
Commission) rules.
Ingress Protection: The first 2 indicates protection from the ingress of solid foreign objects
12.5 mm in diameter and greater. The second 2 indicates protection from the ingress of
vertically falling water drops when the enclosure is tilted not greater than 15 degrees from
vertical.
