Wear a dust lter mask.
Wear ear protection.
Wear safety glasses or a visor.
Wear safety gloves.
Approved in accordance with
the relevant directives.
Recycle discarded product
in accordance with local
regulations.
TECHNICAL DATA
Rated voltae 230 V
~
50 Hz
Output 1100 W
Speed 89 – 271 rpm
Sawing speed 0.7 - 2.4 m/s.
Size L1140 x W13 xT 0,65 mm
Weight 13.7 kg
Sound pressure level, LpA 89.0 dB(A), K= 3 dB
Sound power level, LwA 100 dB(A), K= 3 dB
Vibration level
a
h, CM
= 6.62 m/ s² K= 1.5 m/ s²
Vibration level
a
h, CM
= 6.08 m/ s² K= 1.5 m/ s²
Always wear ear protection!
The declared values for vibration and noise,
which have been measured according to a
standardised test method, can be used to
compare dierent tools with each other and
for a preliminary assessment of exposure. The
measurement values have been determined in
accordance with EN60745-2-20:2009.
DESCRIPTION
Metal bandsaw with base plate for sawing in
metal proles. Fitted with integrated LED light
source.
PARTS
1. Tensioning arm
2. External carbon brushes
3. Support handle
4. Motor casing
5. Speed control
6. Power switch
7. Guide
8. Saw blade
9. Head bearing
10. Switch for work light
11. LED work light
FIG. 1
ASSEMBLY
WARNING!
Pull out the plug before adjusting or replacing
accessories.
FITTING THE GUIDE
Fit the guide (7) before use.
1. Undo the screws on the bracket.
2. Place the guide (7) round the saw blade.
3. Tighten the screws.
USE
Switch the LED work light on and o with the
switch (11).
