34
DESCRIPTION OF SYMBOLS
B1: Read the operating instructions carefully before use.
B2: Keep other people away from the work area.
B3: Risk of injury to hands and feet. Remove the spark plug before carrying out any repairs.
B4: Fuel is ammable; keep the lawnmower away from re. Never ll the fuel tank while the engine is running.
B5: Wear protective glasses and ear protection while mowing.
B6: Hazardous exhaust fumes. Do not use the lawnmower in enclosed spaces with no ventilation.
B7: Hot surfaces.
TECHNICAL DATA
Net weight 28,4 kg
Engine displacement 141 CC
Nominal engine output 2.4 kW
Nominal rpm 2 800 rpm
Cutting width 457 mm
Cutting height 25-75 mm
Propulsion Self-propelled
Collector volume 50 l
Sound pressure level, LpA: 81 dB(A), K= 2,5 d
Measured Sound power level, LwA: 94 dB(A), K= 2,5 dB
Guaranteed Sound power level, LwA: 96 dB(A), K= 2,5 dB
Vibration level: 6,8 m/s2, K= 1,5 m/s2
Always use hearing protection!
B1 B2 B3 B4 B5 B6 B7
