EN
60
Battery and charger sold separately.
USE
INTENDED USE
The circular saw is battery powered and designed for cross and rip cuts and bevel sawing of hard and
soft wood and boards. It can also be used for plunge cutting.
BEFORE USE
• Carefully unpack the circular saw and inspect it. Familiarise yourself with the circular saw’s
controls and use.
• Check that all parts are included and are in a good condition. Do not use the machine if any
parts are missing or damaged.
1. Line 0°
2. Line 45°
3. Bevel angle lock knob
4. Direction indicator
5. Bevel angle scale
6. Front handle
7. Lock button
8. Power switch
9. Main handle
10. Battery mount
11. Blade
12. Connection for dust extractor
13. Locking lever bottom guard
14. Blade ange
15. Blade screw
16. Base plate
17. Bottom guard
18. Direction indicator
19. Parallel fence
20. Depth scale
21. Depth stop lock knob
22. Ventilation openings
23. Spindle lock
24. Lock button
25. Fence lock knob
26. Slot for parallel fence
27. Charging indicator
28. Battery charger
29. Blade spanner
