Megger BM21 - Features and Controls

5
Features and Controls
BM11D Front Panel Layout
12 V Charger Input
Mains Socket
Sliding Cover (open)
Terminal Voltage
Cursor
Cursor
Timer
Selector Keys
On / Off Button
Fuse FS2
Fuse FS1
Warnings
Battery Symbol
Test Button
HV Warning LED
