CONTENTS
CONTENTS 2
INTRODUCTION 3
G SAFETY WARNINGS 4
G LIVE EARTH SAFETY PRECAUTIONS 5
G BATTERY INSTALLATION 5
G BATTERY CHARGING (DET4TCR2 and DET4TR2 ONLY) 5
GENERAL DESCRIPTION 6
PREPARATIONS FOR USE 9
GENERAL OPERATING INSTRUCTIONS 10
INSTRUMENT ILLUSTRATIONS 12
BATTERY 18
DESCRIPTION OF TESTS 23
PREVENTIVE INSTRUMENT MAINTENANCE 60
TECHNICAL SPECIFICATION 61
REPAIR AND WARRANTY 64
End of life disposal 65
Symbols used on the instrument are:
G Caution: refer to accompanying notes
t Equipment protected throughout by Double Insulation
c Equipment complies with current EU directives
Equipment complies with “C tick” requirements
Do not dispose of in normal waste stream
CAT IV 100 V Over voltage category IV is for equipment installed at or near the origin of the electrical
supply to a building.
100 V refer to the rms phase-to-earth voltage that this instrument can withstand to
the overvoltage category IV rating
Note: The safety warnings provided in this document are indicative of safe practice and shall not be considered
exhaustive. Additionally, they are not intended to replace local safety procedures where the instrument is being
used.
Note: This user guide uses the terms ‘earth’ and ‘ground’ interchangeably.
