DET4 Series
Earth/Ground Resistance & Soil Resistivity Testers
Model No. DET4TD2 DET4TR2 DET4TC2 DET4TCR2
Cat. No. 1000-347 1000-324 1000-345 1000-346
2-Pole Measurement n n n n
3-Pole Measurement n n n n
4-Pole Measurement n n n n
Soil Resistivity n n n n
Tests ART (Attached Rod n n
Technique) Capability
Stakeless (Clamp-on) n n
Measurement Capability
Resistance Range 0.01 to 20,000 Ω 0.01 to 200,000 Ω
Ground Voltage Range 0 to 100 V
Ground Current Range 0.5 mA to 19.9 A
(with ICLAMP) Capability
Output Selectable Voltage (25/50 V) n n n n
Test Frequency 128 Hz 94, 105, 111, 128 Hz
Power Supply Alkaline Batteries n n
Rechargeable Batteries n n
Noise Rejection 40 V Peak-to-Peak n n n n
Safety Rating CAT IV 100 V n n n n
Ingress Protection Rated to IP54 n n n n
Hard Carry Case n n n n
Included Accessories Test Leads (49 ft, 33 ft, n n n n
33 ft, 10 ft) and Spikes
Certificate of Calibration n n n n
Warranty 2 Year n n n n
SELECTION GUIDE
CONFIGURATION OPTIONS
Power
Included Accessories Supply
Model No. Cat. No.
DET4TC2+Clamps 1000-365 n n n n n n
DET4TC2+Kit 1000-404 n n n n n n n
DET4TCR2+Clamps 1000-366 n n n n n n n
DET4TCR2+Kit 1000-405 n n n n n n n n
*The Professional Ground Testing Kit (C/N 6320-245) includes two 164 ft (50 m) leads and two 98 ft
(30 m) leads on retractable reels, four auger-style ground spikes, a tape measure and a separate hard
carry case.
NOTE: Using the ICLAMP allows the operator to make ART measurements. Using the ICLAMP and
VCLAMP allows the operator to make stakeless (clamp-on) measurements.
Hard carry case 4 Right-angle terminal adapters External ac/dc Adapter Field Calibrator ICLAMP and VCLAMP Earth/ground kit, C/N 6320-245
Alkaline batteries
Rechargeable batteries Leads (49 ft, 33 ft, 33 ft, 10 ft) and Spikes
