Megger DET4 Series User Manual

14
DET3TD
LCD display
Voltage measurement settings
Test lead connections (at
rear)
Resistance measurement
settings (2P and 3P)
Selector switch
Test lead connections (at rear of instrument)
Test button
25 V/50 V output voltage select button
Output voltage
indicator
Battery charge
indicator
Warning – refer to
user manual
Ruptured fuse
indicator
Potential probe
Resistance indicator
(OK or high)
Current probe resistance
(OK or high)
Ground noise voltage
indicator (OK high)
Measuring range
Over/
under
range
indicator
