EC6000 Changegiver - Operators Guide
MEI, 2008 Page 2 Rev: G2
COIN JAMS
The EC6000 Coin Path is fully accessible. No screwdrivers are required.
To open up the full coin path to check for jammed coins, remove the cassette, open the validator and
open the display panel by releasing the locking clip on the left hand side.
CLEANING
Use only a soft damp cloth, a small light brush and dry cloth. DO NOT use solvents or abrasives.
Display Locking Clip Release
