MEI CASHFLOW SC / SC Advance Page-13
Red conditions - Hard Fault. One of the note acceptor components needs to be replaced.
Yellow condtions - Soft Fault The operator can correct the issue at the machine.
Green conditions - No Fault No problem with the note acceptor.
TROUBLESHOOTING
Universal BEG Diagnostic Codes:
Bezels* on the CASHFLOW SC
®
and SC Advance
®
have two green LEDs above the opening of
the bill path. These LEDs will ash at a rate of once per second when ready to accept a bill. The
LEDs will be off once a bill has been inserted, the acceptor is in calibration mode or the unit is in
software download mode. The LEDs will repeat a ash code in a xed pattern (half second blinks
separated by a two seconds off) to signal a particular code. These codes are listed below.
Flash Code Reason for Flash Code
2 Acceptor is disabled or waiting for interface
4 Bill path is jammed
5 Cashbox removed or cashbox not home
Rapid Blinking Cassette full
* Note: LEDs not available on units that have straight feed bezels or shelf bezels. e Out of Service line will toggle in concert
with the ash codes.
EASITRAX Soft Count Diagnostic Codes (MMI LED)
LED Indicator Status You need to...
Green(Left) - Off
Yellow(Center) - Off
Red(Right) - 4 Flashes
Asset number mismatch betweeen
machine and cashbox RF tag
Insert cashbox with matching or blank asset number.
Green(Left) - Off
Yellow(Center) - Off
Red(Right) - 5 Flashes
RF tag not found Insert cashbox with an RF tag.
Green(Left) - Off
Yellow(Center) - Off
Red(Right) - 6 Flashes
RF tag communication errror Reseat cashbox or replace with a cashbox that has
another RF tag.
Green(Left) - Off
Yellow(Center) - Off
Red(Right) - 7 Flashes
Asset number not found Enter an asset number into the acceptor head using
STS.
Green(Left) - Solid
Yellow(Center) - Solid
Red(Right) - Solid
Checking tag status Wait 5 seconds to determine if Antenna PCB is
found. If not found, replace Antenna PCB.
Green(Left) - Flash
Yellow(Center) - Flash
Red(Right) - Flash
Checking tag status Wait 5 seconds to determine if Antenna PCB is
found. If not found, replace Antenna PCB.
MMI Diagnostic LED Codes:
