32
REPLACEMENT PARTS LIST
V01
PART DESCRIPTION QUANTITY PART DESCRIPTION QUANTITY
1 Chopping Board 1 2 Transformer 1
3
Granite Main
Countertop
1 4 Sink Support Long 2
5 Sink with Drainer 1 6 Sink Support Short 2
7 Side Firebox Assembly 1 9 Ignition Pin Assembly 2
10 Middle Cart Panel 1 11 Left Rear Panel 1
12 Rear Side Cart Panel 1 13 Left Side Cart Panel 1
14
Control Panel Support
Wire
2 15 Glide Support 2
16 Glide 6 17
Top Drawer
Assembly
1
18 Door Handle 3 19 Lower Drawer 1
20 Cart Crossbeam 1 21 Door Crossbeam 1
1 23 Ignitor 1
24 Switch 1 25 Control Panel 1
26 Handle Base 8 27 Panel Handle 1
28A Manifold 1 28B Regulator 1
29 LED Light Bezel 3 30 Control Knob 3
31 Knob Bezel 3 32 Bumper 1
33 Base Panel Assembly 1 34 Door Assembly 1
35 Castor 2 36 Castor With Lock 2
37 Glide Stop 1 38
Cylinder Mandril
Screw Assembly
1
39 Cylinder Tray Assembly 1 40 Fat Cup Assembly 1
41 Heat Shield 5 42 Right Side Cart Panel 1
43 Left Door Support 1 44 Right Rear Panel 1
45 Firebox Support 1 46 Side Burner Bellows 1
47 Side Burner Assembly 2 48
Griddle Burner
Assembly
1
49 Side Burner Ignition Pin 2 50 LED Light Assembly 1
51
Side Burner Shelf
Assembly
1 52
Circuit Light Heat
Shield
1
53 Side Burner Trivet 1 54 Cast-Iron Griddle 1
55 Faucet Assembly 1 56 Control panel support 1
57 Hardware Pack 1 58 Drain Hose 1
59 Grill Cover 1 60 Inlet Pipe 1
61A Ignition Wire Long 1 61B Ignition Wire Short 1
62
Main Burner Ignition
Pin
1 63
Ignition Pole
Assembly
1
