C6010 Printing with your C6010 printer
5 December 2012 – v1.0
Page 54 of 100
Tray 2 can hold up to 20 sheets at a time.
To print from Tray 2:
1. Remove the external packing tape as illustrated below if you have not done so, and then
open Tray 2 to load papers.
2. Raise Tray 2 into position as shown, using the paper feed open tab. Tray 2 should lock
into place.
