LOCATION OF CONTROLS
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
1. CD Compartment
2. FUNCTION Button
3. TIMER Button
4. PRESET/FOLDER
+ / - Button
5. PROG./MEMO./
Clock Set Button
6. Power Button
7. AUX IN, Headphones &
A/V OUT Jacks (Rear of
Unit)
(AV CABLE PART NO.
2076-6921504-4001*)
8. Left Speaker
9. Subwoofer (Bottom of Unit)
10. Tune/Skip/Time
Up (+) Button
11. PLAY/PAUSE (
®p) Button
12. REPEAT Button
13. VOLUME + / - Buttons
14. STOP/BAND (
■) Button
15. Tune/Skip/Time
Down (-) Button
16. CD Compartment Press to
Open Area
17. iPod Dock with Connector,
Dock Adapter & Inter-
changeable Universal
Docks
18. FM Wire Antenna
(Rear of Unit)
19. Right Speaker
20. AC Power Cord
(Rear of Unit)
21. Remote Sensor
22. Display
*Consumer Replaceable Part
(See page 32 to order.)
