LOCATION OF CONTROLS
5
6
7
8
9
10
11
12
13
14
16
17
15
18
2
1
3
4
1. Screen
2. Remote Sensor
3. SD/MMC/MS/xD Card Slot
(Side of Unit)
4. CF Card Slot (Side of Unit)
5. Navigation
† Button
6. Navigation
π Button
7. ENTER/PLAY Button
8. Wall Mount Hole
9. Stand
10. Wall Mount Hole
11. Navigation
®/
VOLUME + Button
12. Navigation
√/
VOLUME - Button
13. Power Button (Side of Unit)
14. USB Jack (Side of Unit)
(
USB CABLE PART NO.
337-01000-E050*)
15. EXIT/CANCEL Button
16. Headphones Jack (Side of
Unit)
17. DC 12V IN Jack (Side of
Unit)
(
AC ADAPTER PART NO.
295-04981-E000*)
18. Speakers
*Consumer Replaceable Part
(See page 21 to order.)
MAIN UNIT
