Two person assembly recommended
a. Attach the Weight Stack Cover (21) to the Weight Stack Cover Support (5) using 6 × M10×16mm Allen
Bolts (60) and 6 × Ø10mm Washers (69).
b. Connect the Single Strap (57) and Pull Bar (24) to the cable using 7# Carabiner (72) and 15 Link
c. Loosen the M10 Aircraft Nut (70) before you connect the 15 Link Chain (71) with the U-shaped
connector (52), and then secure it.
d. If you also buy the 4594828 Dumbbell Bench, connect it with the MH Cable Cross Over using 120×45
Bracket (28) and 2 x Lock Knobs (37).
Notes
：
part (55) and (56) are pre-assembled. If you want to exercise with the Lat bar (13),
Saddle-Shaped Strap (23) and Tricep Rope (59), just replace the Pull bar (24).
