Merach MR-S19 - Assembly Instructions; Install the Foot Tubes

A.Removepre-assembledCuredWasher(#23)andCapNuts(#24)fromtheFrontFoot
Tube(#21)andRearFootTube(#22).
B.Use4CuredWasher(#23)and4CapNuts(#24)toinstallFrontFootTube(#21)andRear
FootTube(#22)ontoMainFrame(#8)bytheClosed-endSpanner#C).
Note:Pleaseensurethebothtubesareinstalledonthecorrectpositionasshownbelow.
C.TightenCapNuts(#24)atthebothfoottubes.
Note:TheCuredWasher(#23)andCapNuts(#24)ispre-assembledontothefoottube.
05
AssemblyInstructions
Step1:InstalltheFootTubes
