Merach MR-S19 - Lock the Back Cushion and Rear Handle

Step2:LocktheBackCushionandRearHandle
A.AttachtheSeatCushion(#10)totheBackrestSupport(#18)withPanHeadHexagonSocket
FullToothScrews(#12)bytheAllenKey(#A).
B.AttachtheBackrest(#26)totheBackrestSupport(#18)withPan-headHexagonSocketSet
Screws(#14)bytheAllenKey(#A).
C.AttachtheRearHandle(#15)totheBackrestSupport(#18)withSeatHandleHook(#16)and
PanHeadHexagonSocketFullToothScrews(#17)bytheCrossHexagonWrench(#B).
Note:The2PanHeadHexagonSocketFullToothScrews(#17)ispre-assembledontotheSeatHandle
Hook(#16).
Note:TheRearHandle(#15)isrotatable(maximum90degrees)fortheusertoseatinto
cushioneasily.
06
AssemblyInstructions
