The release levers (2) are located in different positions
depending on the equipment installed:
Maintenance flap variant A
(Actros)
Maintenance flap variant B
(Actros)
W88.60-A003-71 W88.60-A007-71
Variant A: There is one release lever (2) each on the left
and right in the radiator grille (1) next to the Mercedes
star.
Variant B: There are release levers (2) under the side
paneling above the headlamps.
• To open variant A: Push both release levers (2)
outward in direction of arrow.
• To open variant B: Push left and right release levers
(2) in direction of arrow one after the other.
•
Swivel maintenance flap (1) upward.
• To close: Swivel maintenance flap (1) down until it
locks audibly.
Maintenance flap
Actros, Antos and Arocs | Towing and recovery 19
