Page 8 of 12
6. Assembly and start up
Connection diagrams are show on pages 9 … 12.
1. Wind/rain sensor - 4 leads (YTKSY or YDY) from P6 … P8
terminals.
2. Vent opening sensor - 2 leads from P5 terminals. The contact is
closed when the vents are open (optional feature).
3. Remote control module - 8 leads from P1… P4 terminals (optional
feature).
4. Power supply 230 V, 50 Hz should be connected to the P14 terminal
strip. The power supply line for the unit should be protected by
means of a properly marked overload circuit breaker in the switching
station. The recommended circuit breaker: max. 6.3 A.
5. Start-up. Before switching on the power supply, check if the leads
are connected properly.
Note: the leads should be placed and connected in accordance with
relevant standards and basic rules for wiring. In order to connect the unit
you should use leads which satisfy the requirements of current
regulations.
7. Technical specifications.
Item Value
Power supply voltage
230 V
%10
%15
+
−
50 Hz
Rated power 10 VA
Load for relay outputs max. 5 A, 230 V~
Number of control groups
(number of output terminals)
4
Load on auxiliary output terminal (P13) max. 5 A
Working temperature range -5ºC ÷ +50ºC
Climatic grade in accordance with
WBO/11/11/CNBOP/2002
I
Protection level for housing IP 54
Dimensions (H x W x D) 300 x 300 x 150 mm
Compatible sensors RS1-WM1 and RS2-WM1
