Section 6
-
Storage
Page 96
90-864197070 JUNE 2007
c.
Water‑circulating pump hose
a
6143
a -
Drain plug
d.
Fuel‑cooler‑to‑thermostat‑housing hose
a
6144
a -
Drain plug
e.
Check valve
a
6131
a -
Drain plug (if equipped)
103
105
