Section 6
-
Storage
90-864195070 JUNE 2007
Page 119
Drain System Identification
AIR ACTUATED SINGLE POINT DRAIN SYSTEM
6124
a
b
c
d
6125
a
b
c
d
Closed Cooled Models
Seawater Cooled Models
a -
Blue drain plug location
b -
Blue air pump
c -
Air manifold
d -
Green indicators
MANUAL SINGLE POINT DRAIN SYSTEM
b
a
b
6128
a -
Blue handle
b -
Blue drain plug location
THREE POINT MANUAL DRAIN SYSTEM
a
a
6126
a -
Blue drain plug
126
128
