Mercury 1000 Induction - Fitting the Flue and Vent

INSTALLATION
Check the appliance is electrically safe when you have nished.
22
ArtNo.010-0004 Moving the cooker
Fig.7-6
Fig.7-5
Fig.7-8
Fig.7-7
Lowering the Two Rear Rollers
To adjust the height of the rear of the cooker, rst t a 13 mm
spanner or socket wrench onto the hexagonal adjusting
nut (Fig.7-5). Rotate the nut – clockwise to raise – counter-
clockwise to lower.
Make 10 complete (360°) turns clockwise.
Make sure you lower BOTH REAR ROLLERS.
Completing the Move
Unfold the rear edge of the pack base tray. Open the grill
door and right-hand oven door so that you can get a good
grip on the bottom of the fascia panel as you move the oven
(Fig.7-6).
Carefully push the cooker backwards o the pack base.
Remove the pack base tray.
Position the cooker close to its nal position, leaving just
enough space to get behind it.

DO NOT use the door handles or control knobs to
manoeuvre the cooker.
Fitting the Flue and Vent
Fitting the Flue
Remove the four screws from the grill ue opening.
Oer the removable ue up to grill ue opening. Making sure
that the removable ue bottom ange ts inside the xed
ue, secure in place with the four screws (Fig.7-7).
Fitting the Flue Vent
Loosen the three screws in the back of the hotplate. Fit the
ue vent over the screws and slide down (Fig.7-8). Tighten
the screws to secure.
