MAINTENANCE
43
ob00378
Tube Ref No. Description Where Used Part No.
94
Anti-Corrosion Grease Propeller shaft 92-802867Q1
95
2-4-C with Teflon Propeller shaft 92-802859Q1
IMPORTANT: To prevent the propeller hub from corroding and seizing to the propeller shaft (especially in salt
water), always apply a coat of the recommended lubricant to the entire propeller shaft at the recommended
maintenance intervals and also each time the propeller is removed.
7. Flo‑Torq I Drive Hub Propellers ‑ Install forward thrust hub, propeller, continuity washer, rear thrust hub,
propeller nut retainer, and propeller nut onto the shaft.
ob00382
a
b c
d
e
f
a - Propeller nut
b - Propeller nut retainer
c - Rear thrust hub
d - Continuity washer
e - Propeller
f - Forward thrust washer
8. Flo‑Torq II Drive Hub Propellers ‑ Install forward thrust hub, replaceable drive sleeve, propeller, thrust hub,
propeller nut retainer and propeller nut onto the shaft.
b
c
a
d
f
e
ob00421
a - Propeller nut
b - Propeller nut retainer
c - Rear thrust hub
d - Propeller
e - Replaceable drive sleeve
f - Forward thrust hub
