33
90-10126Z00
gob27
1
2
3
4
5
6
7
8
9
10
ob
GENERAL INFORMATION
obn5
COMPONENT IDENTIFICATION
1. Top Cowl
2. Bottom Cowl
3. Water Pump Indicator Hole
4. Drive Shaft Housing
5. Anti-Ventilation Plate
6. Trim Tab
7. Auxiliary Tilt Switch
8. Transom Brackets
9. Gear Case
10.Cooling Water Intake Holes
obd
INFORMATIONS GENERALES
obn5d
IDENTIFICATION DES COMPOSANTS
1. Capot supérieur
2. Capot inférieur
3. Orifice témoin de la pompe à eau
4. Carter de larbre de transmission
5. Plaque anti-ventilation
6. Dérive
7. Interrupteur auxiliaire de relevage
8. Supports de fixation sur le tableau arrière
9. Carter dengrenage
10.Orifices des prises deau de refroidissement
obj
INFORMACION GENERAL
obn5j
IDENTIFICACION DE COMPONENTES
1. Cubierta superior
2. Cubierta inferior
3. Agujero indicador de la bomba de agua
4. Caja del árbol de transmisión
5. Placa de anti-ventilación
6. Aleta de compensación
7. Interruptor de inclinación auxiliar
8. Soportes del espejo de popa
9. Caja de engranajes
10.Agujeros de la toma de agua de enfriamiento
obh
INFORMAÇÕES GERAIS
obn5h
IDENTIFICAÇÃO DOS COMPONENTES
1. Capota Superior
2. Capota Inferior
3. Orifício Indicador da Bomba de Água
4. Alojamento do Eixo de Transmissão
5. Placa Anti-Ventilação
6. Aba de Equilíbrio
7. Interruptor Auxiliar de Inclinação
8. Braçadeiras de Fixação da Travessa
9. Caixa de Engrenagens
10.Orifícios de Entrada de Água de Resfriamento
