Mercury 25 Series User Manual

WIRING DIAGRAMS
107
1 - Starter motor
2 - Starter solenoid
3 - Fuse (15 A)
4 - Rectifier
5 - Tachometer lead wire (optional)
6 - Tachometer (optional)
7 - Separate cord (yellow) (optional)
8 - Separate cord (white) (optional)
9 - Flywheel magneto
10 - Ignition coil
11 - Spark plug
12 - CD unit
13 - Stop switch (optional)
14 - Stop switch
15 - Battery: 12 V, 70 AH (optional)
16 - Neutral switch
17 - Main switch

Mercury 25 Series Specifications

General

Gear Ratio	2.08:1
Horsepower	25 HP
Steering	Tiller
Shaft Length	15 in, 20 in
Starting	Manual
Full Throttle RPM Range	5000- RPM
Fuel Type	Gasoline
