WIRING DIAGRAMS
109
1 - Assist cord (black) (optional)
2 - Tachometer lead wire (optional)
3 - Rectifier
4 - Fuse wire (15 A)
5 - Starter solenoid
6 - Separate cord (white) (optional)
7 - Separate cord (yellow) (optional)
8 - Starter cord
9 - Starter motor
10 - Alternator
11 - Trigger coil
12 - Flywheel magneto
13 - Exciter coil
14 - Choke solenoid
15 - CD unit
16 - Ignition coil
17 - Spark plug
18 - Stop switch (optional)
19 - Meter lead wire (optional)
20 - Cord assembly
21 - Remote control box (see next page)
22 - Battery (12 V, 70 AH)
23 - Battery cord (–) (black)
24 - Battery cord (+) (red)
25 - Assist cord (blue) (optional)
26 - Assist cord (red) (optional)
27 - Meter lamp switch (optional)
28 - Voltmeter (optional)
29 - Speedometer (optional)
30 - Hour meter (optional)
31 - Tachometer (optional)
