Mercury 25 Series User Manual

MAINTENANCE
87
4. Place a block of wood between the gearcase and propeller to
hold the propeller.
27296
5. Remove the cotter pin, propeller nut, and washer.
37520
a
b
c
d
e
f
a - cotter pin
b - Nut
c - Washer
d - Propeller
e - Propeller thrust holder
f - Propeller shaft
6. Pull propeller straight off the propeller shaft. If the propeller is
seized to the propeller shaft and cannot be removed, have the
propeller removed by an authorized dealer.
7. Coat the propeller shaft with Quicksilver or Mercury Precision
Lubricants Anti‑Corrosion Grease or 2‑4‑C with Teflon.
Tube Ref
No.
Description Where Used Part No.
94
Anti-Corrosion
Grease
Propeller shaft 92-802867Q 1

Mercury 25 Series Specifications

General

Gear Ratio	2.08:1
Horsepower	25 HP
Steering	Tiller
Shaft Length	15 in, 20 in
Starting	Manual
Full Throttle RPM Range	5000- RPM
Fuel Type	Gasoline
