FEATURES & CONTROLS
59
Trim up: If the bow falls into the water level when cruising,
trim the trim position pin up.
37883
a
b
c
d
e
f
a - Correct trim
b - Trim down
c - Trim up
d - Trim position pin
e - Up
f - Down
Steering Friction Adjustment
Steering friction can be adjusted according to your preference with
the steering co‑pilot.
Turn clockwise: More friction
