Mercury 300 XS OptiMax User Manual

OUTBOARD INSTALLATION
eng 131
3. Join the top half of the front clamp with the bottom half. Secure both
halves together with cables ties.
a - Top half of the front clamp
b - Cable ties
4. Secure the front clamp into the bottom cowl with the retainer and two
screws.
5. Install the cowl seal.
a - Retainer
a
b
29074
a
29075
