Mercury 40 Jet User Manual

OUTBOARD INSTALLATION
103
!
WARNING
Improper fasteners or improper installation procedures can result
in loosening or disengagement of the steering link rod. This can
cause a sudden, unexpected loss of boat control, resulting in
serious injury or death due to occupants being thrown within or
out of the boat. Always use required components and follow
instructions and torque procedures.
a
c
b
28479
f
d
e
a - Special washer head bolt (10‑856680)
b - Nylon insert locknut (11‑826709113)
c - Spacer (12‑71970)
d - Flat washer (2)
e - Nylon insert locknut (11‑826709113)
f - Use middle hole ‑ steer outboard to the side to gain hole
access
Description Nm lb. in. lb. ft.
Special washer head bolt 27 20

Mercury 40 Jet Specifications

General

Cylinders	3
Starting	Electric
Steering	Remote
Shaft Length	20 in
Horsepower	40 HP
Alternator Output	226-watt
Warranty	3 years
