OUTBOARD INSTALLATION

105

FUEL HOSE CONNECTION

Fasten the remote fuel hose to the fitting with a metal hose clamp

or the plastic type hose clamp that is provided with the outboard.

28511

a - Hose clamp

b - Remote fuel hose

Electrical Connections and Control Cable

Installation

REMOTE WIRING HARNESS

Remove the access cover.

28696

a - Access cover
