OUTBOARD INSTALLATION
106
Route the remote wiring harness through the rubber grommet.
Connect the 14 pin connector to the engine harness. Fasten the
harness with the retainer.
a
b
c
28697
a - Remote wiring harness
b - Retainer
c - 14 pin connector
THROTTLE CABLE INSTALLATION
Install the cables into the remote control following the instructions
provided with the remote control.
1. Place the throttle cable on the throttle lever pin and lock in
place with the retainer.

Mercury 40 Jet Specifications

General

Cylinders	3
Starting	Electric
Steering	Remote
Shaft Length	20 in
Horsepower	40 HP
Alternator Output	226-watt
Warranty	3 years
