12. Tighten the bilge drain plug.
13. Remove the oil filler cap. Add oil to bring the level up to, but not over, the
"FULL" mark on the dipstick.
IMPORTANT: Always use the dipstick to determine exactly how much oil is
required.
a - Crankcase oil filler cap
Tube Ref
No.
Description Where Used Part No.
25W-50 Synthetic
Blend 4-Stroke
Racing Engine Oil
Crankcase 8M0078013
DRIVE UNIT OIL (BRAVO ONE XR MODELS)
Mercury Racing Gear Lube is now available for use in your drive unit. This oil
will increase the service life of your drive unit when used in place of other oils.
Do not mix Mercury Racing Gear Lube with any other oil.
1. Remove the propeller, place the drive unit in full down position, remove
the oil fill/drain screw and sealing washer, and drain the oil.
a - Oil fill/drain plug
2. Remove the oil vent screw and sealing washer. Allow the oil to drain
completely.
MAINTENANCE
58 eng
