NOTICE
Operating the engine with a loose propeller can damage the propeller, the
drive, or drive components. Always tighten the propeller nut or nuts to
specification and check for tightness periodically and at the required
maintenance interval.
Installation
1. Apply the following lubricant to the entire exposed surface of the propeller
shaft:
Tube Ref
No.
Description Where Used Part No.
Extreme Grease Exposed area of propeller shaft 8M0071842
2. Install the Bravo XR replaceable hub propeller components in the order
shown:
a - Propeller shaft
b - Prop hub assembly
c - Propeller assembly
d - Washer
e - Belleville washer
f - Washer
g - Locknut
3. After first use: Retighten propeller nut.
Description
Nm lb‑in. lb‑ft
Propeller nut 75 – 55
b
c
d
e
f
g
a
8020
MAINTENANCE
64 eng
