4.
Anodic block kit (optional) ‑ is mounted to the boat transom. Acts as a
sacrificial anode. Replace as required.
a - Anodic block
5.
Trim cylinder anodes ‑ are mounted on each trim cylinder. To replace
the trim cylinder anodes:
a. Remove the two screws from each anode.
b. Install the new anodes and tighten securely.
a - Screws (2)
b - Trim cylinder anodes (2)
6.
Bearing carrier anode (XR Bravo One) ‑ is located in front of the
propeller, between the front side of the propeller and the gear housing.
Refer to Propellers in this manual for propeller removal and installation.
To replace the bearing carrier anode:
a. Remove the propeller.
b. Remove the two screws from the anode.
c. Install a new anode and tighten securely.
a
8033
7011
a
b
MAINTENANCE
80 eng
