50
CB621
71966
72032
1
2
CA535
1 Trim Cylinder Anodes - are mounted on each trim cylinder. To replace the trim cylinder anodes:
A Remove two screws from each anode.
B Clean mounting surfaces down to bare metal for proper contact.
CB702
2 Bearing Carrier Anode (Bravo One Models) - is located in front of the propeller, between the front side of
the propeller and the gear housing. Refer to “Propeller” section in this manual for propeller removal and installa-
tion. To replace the propeller anode:
A Remove propeller.
B Remove two screws from anode.
C Install new anode and tighten securely.
D Reinstall propeller. See “Propeller Installation” for proper tightening.
