77
CB345
INSTALLATION (BRAVO THREE)
6 Apply a liberal coat of one of the following Quicksilver lubricants
to both propeller shafts: Special Lubricant 101, 2-4-C Marine Lubri-
cant with Teflon, or Anti-Corrosion Grease.
7 Slide forward thrust hub onto propeller shaft, with tappered side
toward propeller hub (Toward end of shaft).
8 Align splines and place propeller on propeller shaft.
9 Install propeller nut. Tighten nut securely. A minimum of 100 lbs.
ft. (136 N·m) torque is required. Check propeller at least after 20
hours of operation. Do not operate with loose propeller.
10Slide aft thrust hub onto propeller shaft, with tappered side toward
propeller hub (Toward end of shaft).
11 Align splines and place propeller on propeller shaft.
12Install propeller nut. Tighten nut securely. A minimum of 60 lbs. ft.
(81 N·m) torque is required. Check propeller at least after 20 hours
of operation. Do not operate with loose propeller.
