GENERAL INFORMATION
9
Report accidents. Boat operators are required by law to file a
Boating Accident Report with their state boating law enforcement
agency when the boat is involved in certain boating accidents. A
boating accident must be reported if 1) there is loss of life or
probable loss of life, 2) there is personal injury requiring medical
treatment beyond first aid, 3) there is damage to boats or other
property where the damage value exceeds $500.00 or 4) there is
complete loss of the boat. Seek further assistance from local law
enforcement.
Specifications
Model Jet 25
Jet power 19 kW (25 hp)
Horsepower 22 kW (30 hp)
Engine idle RPM 950 +/‑ 25 RPM
Full Throttle RPM range 5150‑5850 RPM
Number of cylinders 2
Piston displacement 429 cc (26.3 cu. in.)
Cylinder bore 68 mm (2.68 in.)
Stroke 59 mm (2.32 in.)
Induction system Loop charged with single carburetor
Ignition Capacitor discharge
Alternator Optional 12V/80W/6.7A
Recommended spark plug NGK BR7HS‑10
Spark plug gap 1.0 mm (0.04 in.)
Recommended gasoline Unleaded 87 Octane min.
Recommended oil TCW‑3 pre‑mix (50:1)
Pump type Centrifugal
Impeller 3‑blade stainless steel
Recommended lubricant for the jet pump
driveshaft bearing
Refer to Maintenance
Gear ratio Direct drive
Exhaust system Through‑pump exhaust
Shifting F‑N‑R with side shift
