MAINTENANCE
21
CHECKING SHIFT LINK ROD ADJUSTMENT
Check the shift link rod adjustment in forward shift position. The
correct adjustment will position the shift cam far enough on the
roller in order to lock the reverse gate into forward position. The
reverse gate should not be able to be forced up towards neutral.
Pull on the reverse gate by hand to verify.
a - Shift link rod
b - Shift cam
c - Roller
d - Reverse gate
ADJUSTING SHIFT LINK ROD
1. Place the shift handle into full forward shift position.
2. Adjust the length of the shift link rod so the roller is at the full
end of travel (bottom) in the shift cam when the shift handle is
in forward.
Corrosion Control Anode
An anode helps protect the outboard against galvanic corrosion by
sacrificing its metal to be slowly corroded instead of the outboard
metals.
