Mercury Jet 40 User Manual

FEATURES AND CONTROLS
21
Remote Control Features
Your boat may be equipped with one of the Mercury Precision or Quicksilver remote controls shown. If not, consult
your dealer for a description of the functions and operations of the remote control.
ee
aa
dd
dd
ee
ff
gg
aa
bb
ff
cc
gg
hh
bb
cc
aa
ff
ii
cc
ii
ob00329
a - Control handle - forward, neutral, reverse.
b - Neutral release lever
c - Trim/tilt switch (if equipped). - Refer to Features & Controls - Power Trim and Tilt.
d - Lanyard stop switch - Refer to General Information - Lanyard Stop Switch.
e - Lanyard - Refer to General Information - Lanyard Stop Switch.
f - Throttle friction adjustment - Console controls require cover removal for adjustment.
g - Ignition key switch - off, on, start.
h - Fast idle lever - Refer to Operation - Starting the Engine.
i - Throttle only button - Refer to Operation - Starting the Engine.
Warning System
The outboard warning system incorporates a warning horn inside the boat. Remote control models will have the
warning horn located inside the remote control or connected to the ignition key switch.
a
b
ob00662
a - Warning horn inside remote control b - Warning horn inside key switch
Tiller handle models will have the warning horn located below the tiller handle.

Mercury Jet 40 Specifications

General

Horsepower	40 HP
Cylinders	3
Weight	240 lbs (109 kg)
Steering	Remote
Displacement	45.6 cu in (747 cc)
Starting	Electric
Full Throttle RPM Range	5000 - 6000 RPM
Fuel Induction System	Carburetor
Alternator Output	18 Amp
Shaft Length	20 in
