Fuse/
Relay
Location
Fuse
Amp
Rating
Description
18 30A* Anti-Lock Brake Module
19 15A* Horn Relay, Powertrain Control
Module (PCM)
20 15A* Headlamp Switch, Autolamp
Park Relay
21 — Not Used
22 30A* Autolamps Relay, Multifunction
Switch, Headlamp Switch
23 — Blower Motor Relay
24 — Starter Relay
25 — A/C Clutch Relay
26 30A* Generator
27 10A* A/C Clutch Relay
28 15A* Heated Oxygen Sensors,
Canister Vent
29 — Fuel Pump Relay
30 — PCM Relay
31 — Low Speed Cooling Fan Relay
32 — PCM Diode
33 — A/C Clutch Diode
34 — Not Used
* Mini Fuses ** Maxi Fuses
Relays
Relays are located in the power distribution box and
should be replaced by qualified technicians.
Roadside emergencies
125
