Speedometer
Fuel gauge
When the fuel gauge needle is on
the E (empty) portion of the
gauge, there are between
approximately 2 L (.6 gallons) and
4 L (1 gallon) of usable fuel left in
the tank.
Engine coolant temperature
gauge
If the engine coolant temperature
gauge moves into the H zone:
1. Pull off the road as soon as is
safely possible.
2. Turn off the engine and let it
cool.
3. Check and add engine coolant
as necessary. Refer to Checking
and adding engine coolant in the
Maintenance and care chapter. If
the coolant level and mixture is
not properly maintained, the
engine coolant temperature gauge
will not read properly.
0000
000000
MPH
km/h
10
20
30
40
50
60
70
80
90
10 0
12 0
11 0
20
40
60
80
100
120
160
180
140
200
E F
1
/
2
C H
Instrumentation
13
