2. Remove the bulb assembly form
the interior recess.
3. Twist the bulb counterclockwise
to remove it and secure a new
bulb.
4. Replace the bulb assembly in
the interior recess and replace the
access panel.
Interior overhead lamp
The interior overhead lamp is
located on the center of the ceiling
of the vehicle. To replace the
bulbs:
1. Remove the lamp lens by
applying pressure to both tabs at
the top of the lamp assembly and
pulling the lens down and off.
2. Pull the bulb to remove it and
secure a new bulb.
3. Replace the lamp lens by
applying pressure to both sides of
the lamp lens and popping the lens
up and on to the lamp assembly.
OFF DOOR ON
OFF DOOR ON
Maintenance and care
170
