Mercusys MW300RE Quick Installation Guide

English
1
1 Power on
Plug the extender into a power outlet near your router,
and the Signal LED turns solid red.
2 Connect to the extender
Connect your wireless device to the extender’s network
MERCUSYS_RE_XXXX.
Note: The default SSID (network name) is printed on the product
label at the back of the extender.
3 Configure
a) Launch a web browser and enter http://mwlogin.net.
Create a password for future login attempts.
b) Select your router's host network and enter the
network password when prompted.
c) Check the Signal LED on your extender. Green or
orange LED indicates a successful connection.
4 Relocate
To achieve better signal quality, plug in the extender
halfway between your router and the Wi-Fi dead zone.
Router Extender Clients
Host Network
Extended Network
* Image may differ from actual product
.
Enjoy!
Connect your device to the extender using the extended SSID. The
default Wi-Fi password is the same as your host network.

Mercusys MW300RE Specifications

General

Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Certification	CE
Product color	White
LED indicators	Yes
Sustainability certificates	RoHS
Antenna type	External
Antennas quantity	3
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Security algorithms	WPA, WPA-PSK, WPA2, WPA2-PSK
Wi-Fi data rate (max)	300 Mbit/s
Power consumption (max)	4.3 W
Power consumption (typical)	3 W
Type	Network repeater
Maximum transfer distance	- m
Package depth	121.5 mm
Package width	150.5 mm
Package weight	250 g
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	74.8 mm
Width	101 mm
Height	75.8 mm
