Merida Bike - Permitted Torques for Seat Post Binder with allen Bolt; Bottle Cage

114
Seat post binder
Every MERIDA carbon frame includes a
special seat post binder to achieve an opti-
mum clamping power. Only use the included
model.
28.2.10 Permitted torques for seat post
binder with Allen bolt
Use a torque of 6-8 Nm to clamp the seat
post. Do not exceed a maximum torque of
8 Nm!
28.2.11 Bottle cage
Use a torque of 2-3 Nm. Do not exceed a
maximum torque of 3 Nm!
28.2 MERIDA framesets
Ask your MERIDA dealer as to the mounting
of suitable seat post binders. Check whether
frame and seat post diameters match before
mounting.
Never grease the clamping area
between seat post and seat tube when
mounting a carbon seat post.
